Ritter Machinery 6° Low Angle Pocket Cutter

by Ritter Machinery
SKU R2061
Sold out
$7,399.00
$7,399.00 - $9,999.00
$7,399.00
$7,190.00
$7,190.00 - $9,540.00
$7,190.00
Shipping: $499
  • ✔ Fast & Safe Shipping Right To Your Workshop
  • ✔ Questions? Speak with a Team Member Today: (973) 319-8415
Availability:
Out of stock
Availability:
Out of stock
Availability:
Out of stock
Availability:
Out of stock
Shipping information

Orders are processed in 2–3 business days. Ground orders typically arrive in 7–10 business days. Orders over 100 lbs ship LTL freight and are scheduled with the carrier. Shipping is quoted at checkout or before fulfillment, and we ship within the United States only. See our Shipping Policy.

Returns & warranty

Every machine is sourced directly from the manufacturer and covered by the full manufacturer warranty. Report shipping damage immediately so we can help. Return terms vary by manufacturer — see our Return and Refund Policy.

The Ritter R2061 Pocket Hole Machine is designed for pocket hole cutting in cabinet face frame assembly and woodworking joinery applications. The machine uses a 6° low-angle pocket hole design to support accurate screw pocket placement during assembly.

The machine operates using a PLC-controlled cutting cycle and foot pedal actuation. Adjustable material stops allow operators to position workpieces consistently during production operations.

Standard Features

  • 6° low-angle pocket hole cutting system
  • PLC-controlled machine cycle
  • Foot pedal operated cutting cycle
  • Adjustable material stops
  • Material capacity up to 2" thickness
  • Cycle time approximately 1.75–2 seconds
  • Tooling included

Typical Applications

  • Cabinet face frame assembly
  • Casework production
  • Furniture joinery
  • Pocket hole machining for woodworking components

Technical Data + Specifications

Router Bit 3/8" solid carbide rough mill
Drill Bit 9/64" brad and spur TiN-coated bit
Router Motor 24,000 RPM, 12 A, 2.25 HP
Drill Motor 31,000 RPM, 4.5 A, 7/8 HP
Electrical Requirement 110V, 15A
Air Requirement 2 CFM at 80–100 PSI
Work Height 36 in
Machine Footprint 27.75 in x 20.5 in
Table Area 15.75 in x 23.75 in
Dust Port 4 in

Additional Options

  • 48" wide table
  • R2063 – 3-phase 230/460 volt configuration

Shipping Information

Shipping Weight 300 lbs
Shipping Dimensions 38 in x 25 in
